Name: Dell PowerEdge R770 Rack Server
Brand: Dell
SKU: 4039
Availability: InStock

Do you experience poor processing speeds with virtualization or AI workloads? The Dell PowerEdge R770 Rack Server is a two-socket, 2U rackmount server with high computing abilities to grow with today’s modern datacenter workloads. The PowerEdge R770 offers a huge number of processing cores by Intel’s Xeon 6 series processors, faster DDR5 memory, and the flexibility of using different types of storage drives. With its performance capabilities in the cloud, analytics, and enterprise application domains, the Dell R770 is designed to use resources efficiently and effectively.

Key Features Of Dell PowerEdge R770 Server

Robust Dual Intel Xeon Processors with Extra PCIe Gen 5 Functionality

With two Intel Xeon 6 CPUs that support either 144 E-cores or 86 total P-cores on each, the R770 can process several operations in parallel. It is designed to provide maximum expansion opportunities for both GPUs, DPUs, and storage controllers for compute-intensive and interactive workloads, with acceleration for AI applications.

Flexible Memory Capacity and Storage

The PowerEdge R770 can expand up to 8TB of ECC memory in 32 RDIMMs with speeds of 6400 MT/s. Large VMs and extensive databases benefit from this flexibility. The server allows you to use different storage technologies, either by using 40x EDSFF Gen5 NVMe or up to 24x 2.5″ SATA/SAS drives. It provides the enterprise databases with greater bandwidth and added capacity for continuous business growth.

Benefits Of Dell PowerEdge R770

Accelerate AI & Analytics

To accelerate AI inferencing/machine learning, the Dell R770 system provides faster insight with improved processing speeds for data-driven applications by using up to two 450 Watt double-width, seven 75 Watt single-width graphics cards, and three (BF3) DPUs.

Enterprise Apps & Big Databases

All mission-critical applications, ERP systems, and scale-out databases are supported by reliable performance through the integrated high-quality compute, memory, and storage architecture of the R770. The use of NVMe high-speed storage reduces the latency associated with data-intensive workloads.

Optimized for Virtualization & Cloud Environments

Numerous virtual machines can be operated more effectively with high processor core counts and large memory sizes. Stable throughput within the R770’s scalable cloud and hyperscale infrastructures results in reduced cost of ownership and improved consolidation of workloads.

Why Choose ServerBasket?

Lowest Prices

Every Dell R770 from ServerBasket comes at a lower cost than any other seller, helping you maximize ROI while acquiring high-quality data center growth.

Configurable Versions

You will be able to configure your server using your choice of processor, RAM, storage, GPUs, DPUs, or networking devices according to your use case.

Standard Warranty

Each Dell R770 comes with a 3-year product warranty, including free repairs and replacements within the tenure. Experience a reliable performance with minimum downtime and greater peace of mind.

Technical Specifications

Specification	Details
Brand	Dell
Server Model	PowerEdge R770 Rack Server
Processor	Dual Intel Xeon 6 processors Up to 144 E-cores OR 86 P-cores per CPU
Memory	32× DDR5 DIMM slots Up to 8 TB RDIMM Speed up to 6400 MT/s Registered ECC DDR5 supported
Storage Controllers	Boot: BOSS-N1 (HW RAID 1, dual M.2 NVMe / USB) Internal: PERC H965i / H975i / H365i
Drive Bays (Front & Rear)	Up to 40× EDSFF E3.S Gen5 NVMe (2457.6 TB) Up to 32× EDSFF E3.S Gen5 NVMe (1966.08 TB) Up to 16× E3.S NVMe (983.04 TB) Up to 8× E3.S NVMe (491.52 TB) Up to 24× 2.5" SATA (92.16 TB) Hybrid: 16× SATA + 8× NVMe (552.96 TB) Rear: Up to 4× E3.S NVMe (245.76 TB)
Max Storage	2457.6 TB NVMe
GPU Support	Up to 6× 75W FHHL GPUs Up to 2× 450W DWFL GPUs
DPU Options	NVIDIA BlueField-3 (2×200 GbE / 1×400 GbE)
PCIe Slots	Up to 8× PCIe Gen5 slots (x8/x16) Supports FHHL, DWFL, OCP 3.0 configurations
Network Options	OCP NIC 3.0 (up to 2 slots front/rear)
Power Supply	800W / 1100W / 1500W / 1800W / 2400W / 3200W Platinum & Titanium efficiency AC, DC & HVDC options Hot-swappable redundant
Cooling	Air Cooling Direct Liquid Cooling (DLC supported)
Fans	High-performance Silver/Gold fans Up to 6 hot-swappable fans
Form Factor	2U Rack Server
Management	iDRAC, iDRAC Direct REST API (Redfish), RACADM CLI iDRAC Service Module Quick Sync 2 NativeEdge (optional)
Security	Secure Boot & Signed Firmware TPM 2.0 Certified Silicon Root of Trust System Lockdown Data Encryption (SED) Intrusion Detection
Operating Systems	Ubuntu Server LTS Windows Server (P-core only) RHEL SUSE Linux VMware ESXi Dell NativeEdge OS
