Name: Dell PowerEdge R740xd Rack Server
Brand: Dell
SKU: 2866
Availability: InStock

If you’re looking for a server that will help you effectively manage virtualised workloads that require heavy compute power, storage capacity, and analytics capabilities, the R740xd is your solution. This 2U server features up to two Intel Xeon Scalable processors (each with up to 28 cores), three terabytes of DDR4 RAM, and maximum expandability via eight PCIe 3.0 slots. Storage replication and multiple PERC RAID controllers enable users to add up to 24 2.5″ drives or 12 3.5″ drives (NVMe/SAS/SATA), offering a maximum of 288 terabytes of usable storage. The Linux version of the Dell PowerEdge R740xd also supports up to 3 GPUs or FPGAs using a PCIe 3.0 expansion card. It features eight PCIe 3.0 slots for installing additional peripheral devices, so the R740xd is well-suited for virtualisation, disaster recovery, database applications, and large content repositories.

Dell PowerEdge R740xd 24SFF Price List in Uganda:

Server Model	Processor	Memory	Storage	Price
Dell PowerEdge R740XD Rack Server (Basic)	24 cores (2 x Intel Xeon Gold 6226, 12 Cores each)	128GB DDR4 RAM	2 × 480GB SSD (960GB SATA SSD)	UGX 13,980,739
Dell PowerEdge R740XD Rack Server (Standard)	24 cores (2 x Intel Xeon Gold 6226, 12 Cores each)	256GB DDR4 RAM	3 × 480GB SSD (960GB SATA SSD)	UGX 17,633,449
Dell PowerEdge R740XD Rack Server (Essentials)	48 cores (2 x Intel Xeon Platinum 8260, 24 Cores each)	512GB DDR4 RAM	2 × 480GB SSD (960GB SATA SSD), 3 x 960GB SATA SSD	UGX 31,594,909
Dell PowerEdge R740XD Rack Server (Premium)	48 cores (2 x Intel Xeon Platinum 8260, 24 Cores each)	768GB DDR4 RAM	2 × 480GB SSD (960GB SATA SSD), 3 x 1.92TB SATA SSD	UGX 47,281,259

High Computing Power, Memory, and Expandability

This server supports the installation of up to 2 Intel Xeon Scalable CPUs, 7.68TB of DDR4 Memory (2933MT/s), and up to three double-width GPU or FPGA cards. Featuring 8 PCIe 3.0 slots, it allows the addition of hardware accelerators, NVMe expansion cards, and any extra storage adapters. With its ability to perform high levels of computation, it is perfectly suited for Virtual Desktop Infrastructure (VDI) workloads, SDS, AI inference, service providers, and enterprise applications that need to operate simultaneously.

Enormous Storage Capacity and Advanced Networking Options

With its 24 SFF or 12 LFF bays, the Dell R740xd can accommodate NVMe/SAS/SATA drives, providing up to 288 terabytes of total storage capacity and fast data access through the use of Dell’s PERC RAID controllers (H330, H730P, H740P, HBA330). It is designed for software-defined storage, database solutions, and high-density storage environments. The server also has multiple networking options, including four 1 GbE or 2 10 GbE ports on the motherboard, as well as optional 10/25/40 GbE and Fibre Channel connections.

Questions? We're here to help

From offering expert advice to solving complex problems, we’ve got you covered.

Why Choose ServerBasket?

Fast, Safe Delivery Across Uganda

Using our secure and fast fulfilment service, ServerBasket in Uganda guarantees the timely delivery of your Dell PowerEdge R740xd, using high-quality packaging and fully reliable logistics.

Comprehensive 3 Year Warranty

Additionally, each new Dell R740xd server is covered by a 3-year manufacturer’s warranty, providing peace of mind regarding the quality of hardware. You will receive replacement support if necessary to ensure your business runs smoothly.

Expert Configuration & Deployment Assistance

We can assist you with tailoring your Dell R740xd to your workload requirements by offering configuration assistance, remote installation, RAID setup, and performance optimisation to facilitate a smooth deployment.

Technical Specifications

Brand	Dell
Server Model	Dell PowerEdge R740xd Rack Server
Server Type	Rack Server
Form Factor	2U
Processor	2 x Intel Xeon Processor Scalable Family
Maximum Cores	Up to 56 Cores
Memory Capacity	Up to 7.68 TB (12 × 512 GB Intel Optane Persistent Memory + 12 × 128 GB LRDIMM) Up to 3 TB (24 × 128 GB LRDIMM)
Memory Slots	24 DIMM Slots
Storage Support	HDD & SSD
Drive Types	SAS / SATA / NVMe
Network Ports	4 × 1 GbE or 2 × 10 GbE + 2 × 1 GbE or 4 × 10 GbE or 2 × 25 GbE.
PCIe Slots	Up to 8 × PCIe Gen3
Accelerator options	Up to 3 GPUs (300 W) or up to 6 GPUs (150 W) Up to 3 double-wide FPGAs or up to 4 single-wide FPGAs
Security	TPM 1.2 / TPM 2.0 support Secure Boot System Lockdown Mode Firmware & Data Protection Secure Erase
Supported RAID Controller’s	Internal Controllers: PERC H330, PERC H730P, PERC H740P, HBA330 External Controllers (RAID): PERC H840, 12 Gbps SAS HBA
Operating System	Microsoft Windows Server, Linux Distributions, Virtualization & Hypervisors, VMware ESXi, Citrix Hypervisor and more.
Power Supplies	2 units (redundant)
Wattage Range PSUs	495 W to 2400 W 495 W Platinum 750 W Platinum / Titanium 1100 W Platinum 1600 W Platinum 2000 W Platinum 2400 W Platinum
Ideal For	Software Defined Storage, Service Providers or Virtual Desktop Infrastructure.

Frequently Asked Questions (FAQ’s)

What is the Dell PowerEdge R740xd server used for?

Users can use the Dell PowerEdge R740xd server for their enterprise workloads. So, if you intend to target high storage density, you can go for it. The server is the best fit for the virtualization, VMware vSAN, software-defined storage (SDS), VDI, databases, private cloud, AI/ML, and analytics workloads.

How many and what type of processors does the PowerEdge R740xd support?

You can configure the PowerEdge R740xd server with up to two 2nd-gen Intel Xeon Scalable CPUs. It gives solid compatibility with the Gold, Platinum, and M-series CPUs. With scope for up to 56 total cores, in a dual-socket architecture, you can now unlock unbelievable processing performance.

How much memory can it handle?

The Dell PowerEdge R740xd server brings to you a solid memory architecture. You get up to 3TB DDR4 memory by configuring the server with 24 DIMM slots. We help you choose the right RDIMM or LRDIMM modules. These are ideal for memory-intensive workloads, with much faster data access.

What storage options are available on this server?

The PowerEdge R740xd server features a scalable storage architecture, supporting up to 24 × 2.5-inch or 12 × 3.5-inch SAS/SATA drives, with a total raw capacity of up to 153TB. It can accommodate a mix of NVMe, SSD, and HDD drives for optimal performance and capacity.

Which operating systems are supported by Dell PowerEdge R740xd?

There are multiple OS options to choose from for your Dell PowerEdge R740xd server. This includes VMware ESXi, Microsoft Windows Server, Ubuntu Server LTS, Red Hat Enterprise Linux (RHEL), SUSE Linux Enterprise Server, and Citrix XenServer. So, based on the most compatible option, you can go for the right pick.

Do you provide international shipping for PowerEdge R740xd?

Yes. At ServerBasket, we have provisions for international shipping available. We make worldwide delivery free of cost, with provisions for same-day dispatch. Our team makes doorstep delivery across Uganda, with facilities for 24/7 remote support.
